Tube assembly: 2x ECC83 (12AX7)
Input impedance: 10, 50, 100, 1k, 47k ohms
Input capacitance: 50, 150, 300, 400 pF
Gain (+ 6dB using XLR Out): 40, 45, 60, 65 dB
SNR MM (40dB): 97dBV, 105dBV - ‚A‘ weighted
SNR MC (60dB): 83dBV, 88dBV - ‚A‘ weighted
THD at 1 kHz: <0,005% MM, < 0,01% MC
THD (20Hz-20kHz): <0,1% MM, < 0,03% MC
RIAA-equalization curve accuracy: <0,4dB / 20Hz - 20kHz
Subsonic filter: at 20Hz with 18dB/octave
Input: 1x 5-pin mini XLR / 1x pair RCA phono sockets
Line-level output: 1x pair RCA, 1x pair XLR
Power supply DC: 18V/1000mA
Power consumption: 18V/800mA DC, <0.5 W in standby
Dimensions (WxHxD): 206x81x153 (164 with sockets) mm
Weight: 1010g without power supply
