Turntable Section
Drive Method: Direct Drive
Motor: Brushless DC motor
Turntable Speeds: 33-1/3, 45 and 78* rpm
* The turntable speed will be 78.26 rpm when set to 78 rpm.
Starting Torque: 0.18N・m (1.8kgf・cm)
Build-up Characteristics: 0.7 s. from standstill to 33- 1/3 rpm
Braking system: Electronic brake
Wow and Flutter: 0.025% W.R.M.S.
Turntable Platter:
Aluminium die-cast
Diameter：332mm
Weight：Approx. 2.0kg (including turntable mat)
Tonearm Section
Type: Static Balance
Effective Length: 230mm
Overhang: 15mm
Tracking Error Angle:
Within 2° 32' (at the outer groove of 30cm record)
Within 0° 32' (at the inner groove of 30cm record)
Offset Angle: 22°
Arm Height Adjustment Range: 0 - 6mm
Stylus Pressure Adjustment Range: 0 - 4g (direct reading)
Headshell weight: Approx. 7.6g
Applicable Cartridge Weight Range:
(without auxiliary weight):
5.6 - 12.0g
14.3 - 20.7g (including head shell)
(with small auxiliary weight):
10.0 - 16.4g
18.7 - 25.1g (including head shell)
Cartridge Mounting Dimension: 12.7 mm (1/2") interval
Head Shell Terminal Lug: φ1.2mm 4-pin terminal lug
Terminals
Audio Output:
PHONO (Pin Jack) x 1
EARTH TERMINAL x 1
LINE (Pin Jack) x1
General
Power Supply: AC 110-240V, 50/60 Hz
Power Consumption:
For UK
8.0 W (ON)
Approx. 0.2 W (OFF)
For Other Regions
8.0 W (Power ON)
Approx. 0.2 W (Power OFF)
Dimensions (W x H x D): 453 x 169 x 372 mm
Weight: Approx.9.9 kg
Operating temperature range: 0℃ to +40℃
Operating humidity range: 35% to 80% RH (no condensation)
