Drive System: Direct
Motor: 16-pole, 12-coil, brushless motor
Control method: PWM Vector
Platter: Aluminum diecast (305mm)
Platter inertia: 382 kg/CM^2
Wow Flatter: less than 0.06% JIS
Speed tolerance: less than ± 0.3%
Rumble (S/N ratio): Over 70dB
Bearing Type: Miniature Steel ball bearing
Tone Arm: Static Balanced S-Shaped
Arm length: 244 mm
Overhang: 14 mm
Offset angle: 20.5 °
Tracking error angle: 2.5° (Max.)
Suitable cartridge weight:
4 to 16g without sub weight
14 to 26g with sub weight
Stylus force adjustment: 0 - 2.5g /rotation
High adjustment range: 9mm
Anti-skating adjustment: 0-3g
Headshell material: Aluminum
Sensitivity (Horizontal): 30mg
Sensitivity (Vertical): 30mg
Operation: Manual
Speed: 33 1/3 / 45 / 78 rpm
Control: Start / Stop
Dimensions: 500 x 394 x 185mm (W x D x H)
Weight: 18.5 kg
Power Supply: AC 100-240V, 50/60Hz
Power consumption: <4W
Stdby Power consumption: Less than 0.3W
Carton maximum Dimensions: 615 x 515 x 335 mm (W x D x H)
Carton Weight: 24.0 kg
