Mass & Dimension: 7.0g, 18 x 16.5 x 30.8mm (WxHxD)
Stylus: Solid Ultra Low-Mass 75µm x 2.5µm Microridge
Cantilever: ⌀0.28mm Boron Shaft
Coils: High-Purity Copper
Internal Impedance: 35Ω
Load Impedance: 100 – 1kΩ
Frequency Response: 10Hz – 50kHz
Output Voltage: 0.5mV
Channel Separation: 30dB @ 1kHz
Channel Balance: 0.5dB @ 1kHz
Compliance: 12×10-6cm/dyn @ 100Hz
Capacitance: 100pF – 200pF
Vertical Tracking Angle: 20°
Tracking Force Range: 1.9g – 2.2g
Recommended Tracking Force: 2.0g
Replacement Stylus Unit: Re-Tip Exchange
