Display Screen: 3-inch LCD Screen
Chassis: Aviation aluminum alloy
DAC: ES 9038Pro
Audio Processor: XMOS XU316
OPA Chip: OPA1612*10
Power Supply: Low noise switching power supply
Bluetooth Audio Input:
Qualcomm QCC5125 Bluetooth module, BT5.0 Support SBC/AAC
Bluetooth protocol
USB-B DAC Input:
Compatible with Windows (7, 10), Mac, Android and IOS
Up to stereo DSD512, PCM 768KHz 32Bit and MQA
USB-C DAC Input:
Compatible with Windows (7, 10), Mac, Android and IOS
Up to stereo DSD512, PCM 768KHz 32Bit, MQA
Optical Audio Input: Up to stereo PCM 192KHz 24Bit, DSD64 Dop and MQA
Coaxial Audio Input: Up to stereo PCM 192KHz 24Bit, DSD64 Dop and MQA
Analog Audio Output:
Preamp output: XLR (balanced), RCA;
Headphone amp output: 6.35mm single-ended
USB Port: USB2.0*1（only for firmware upgrade
Control Methods: Remote control, mobile APP control and knob control
Headphone Impedance: 16-300Ω （low gain mode:16-32Ω/high gain mode: 32-300Ω）
XLR Audio Characteristics:
Output level(Vrms): 4.1Vrms@0dBFS
THD+N@A-wt: 0.000062%@1kHz（-124dB@1kHz）
THD+N@No-wt: 0.000069%@1kHz（-123dB@1kHz）
Noise@No-wt: <1.2uVrms
SNR @No-wt: 133dB@1kHz
Frequency response: 20Hz-20kHz(±0.1dB)
Crosstalk: -130dB@1kHz
DNR @No-wt: 133dB@1kHz
RCA Audio Characteristics:
Output level (Vrms): 2.3Vrms@0dBFS
THD+N@A-wt: 0.000086%@1kHz(-121dB@1kHz)
THD+)@No-wt: 0.000097%@1kHz(-120dB@1kHz)
Noise @No-wt: <1.5uVrms
SNR @No-wt: 126dB@1kHz
Frequency response: 20Hz-20kHz(±0.1dB)
Crosstalk: -123dB@1kHz
DNR@No-wt: 126dB@1kHz
Headphone (low gain mode):
Output level(Vrms): 1.2Vrms@0dBFS
Maximum undistorted power: 45 mW@32Ω
THD+N@A-wt: 0.00015%@1kHz(-116dB@1kHz)
THD+N@No-wt: 0.00018%@1kHz(-115dB@1kHz)
Noise @No-wt: <2uVrms
SNR@No-wt: 124dB@1kHz
Frequency response: 20Hz-20kHz(±0.1dB)
DNR @No-wt: 119dB@1kHz
Headphone (high gain mode):
Output level(Vrms): 2.8Vrms@0dBFS
Maximum undistorted power: 26 mW@300Ω
THD+N@A-wt: 0.00016%@1kHz(-116dB@1kHz)
THD+N@No-wt: 0.00016%@1kHz(-116dB@1kHz)
Noise@No-wt: <2uVrms
SNR@No-wt: 124dB@1kHz
Frequency response): 20Hz-20kHz(±0.1dB)
DNR @No-wt: 124dB@1kHz
Power Input: AC 110~240V 50/60Hz
Rated Power: 9W
Dimensions: 270mm(W) * 187mm(D)* 50mm(H)
