Frequency Response
On Axis @ 0° ±3dB: 90 - 23,000Hz
LF Cutoff -10dB: 62Hz
Sensitivity
Anechoic Chamber: 83dB
Listening Room: 85dB
Impedance
Nominal: 8 Ohms
Minimum: 6 Ohms
Acoustic Design
Tweeter (Nominal): 1" (25mm) Titanium Dome with Ferrofluid
Woofer (Nominal): 1 x 4" (100mm) Carbon Fibre Cone Rubber Surround
Cast Basket
Design Type: Bass Reflex
Construction
Cabinet: MDF
Grille Face: Acoustic Transparent Cloth
Frame: MDF
Size (W x H x D)
Net W: 12” (305mm)
Net H: 6.5” (165mm)
Net D: 3.38” (85mm)
Depth With Grill: 3.5” (90mm)
Weight
Net: 20 lbs (9.1 kg)
Shipping: 28 lbs (12.7 kg)
Finish
Available Finishes: Satin Black, Satin White
Grille Type: Magnetic, Cloth Grille
