Model: Coda W
Drive units:
Uni-Q Driver Array:
HF: 25 mm (1 in.) aluminium dome
LF/MF: 130 mm (5.25 in.) magnesium/aluminium alloy cone
Frequency range (-6dB) measured at 85dB/1m:
38Hz - 20kHz
*Depends on EQ Settings
Frequency response (±3dB) measured at 85dB/1m:
41Hz - 20kHz
*Depends on EQ Settings
Amplifier output power (per speaker): LF: 70W HF: 30W
Amplifier class (per speaker): LF: Class D HF: Class D
Max SPL measured at 1m: 102 dB
Wireless streaming features:
Bluetooth 5.4
aptX Adaptive™, aptX Lossless™
Source resolution:
Optical up to 96kHz/24bit
USB Type C up to 192kHz/24bit
HDMI up to 1.411 Mbps PCM
*Depends on source resolution
Interspeaker connection:
Wired: all sources resampled to 96kHz/24bit PCM
Dimensions (H x W x D per speaker): 285 x 168 x 268 mm (11.2 x 6.6 x 10.55 in.)
Weight (per set): 11.3kg
Power input: 100 – 240VAC 50/60Hz
Power consumption:
200W (operating power)
<0.5W (standby power)
