Bluetooth Standard: 4.6.45.2, 15m
Bluetooth Transmit: 2x Bluetooth TX, able to connect up to 2 Bluetoothspeaker or earbuds.
Bluetooth Receiver: 2x Bluetooth RX, able to connect up to 2 Bluetoothtransmitter device
Bluetooth Codec:
TX: aptX HD, aptX, aptX AD, aptX LL, AAC, SBC
RX: aptX HD, aptX, aptX AD, AAC, SBC
Power Output:
24V 4ohm 50W *2
24V 8ohm 30w *2
Speaker Impedance: 4 - 8 ohm
Frequency Response: 20Hz to 20Khz
THD + N: Line Out x 1 / 1 Vrms(3.5mm mini jack)<0.1% @ 1W 1kHz
SNR: >93db
Line in: Analog RCA, Max 2V RMS input
Phono in: Analog RCA, support MM/MC
Optical in:
Max 192kHz/24bit sample rate decode
PCM encoding
HDMI ARC: PCM only
USB Host:
USB disk drive playback, support resume playback
Sample rate: 48kHz
Storage format: Fat16, Fat32, exFAT, up to 128GB
Support codec: mp3(data rate up to 384kbps), mp4, wma, mov, m4a, aac, flac(96kHz/24bit), ape
USB Type-C: USB DAC for PC connection, sample rate: 48kHz
Subwoofer out: Max 3V RMS output, Frequency Response: 250Hz
Speaker out: 50W per channel @ 4ohms
Power Input: 24V/4.16A
Size: 185 x 155 x 50mm
Weight: 900g
