Input Voltage: 5V/2.5A
Max Output:
Balanced
>15.1V/385 mW (@ 600 Ohm)
>11.0V/1890 mW (@ 64 Ohm)
>6.2V/1200 mW (@ 32 Ohm)
Single-Ended
>7.6V/98mW (@ 600 Ohm)
>7.4V/870 mW (@ 64 Ohm)
>7.2V/1600 mW (@ 32 Ohm)
THD&N:
Balanced <0.006% (@ 360 mW/2.4V 16
Ohm)
Single-Ended <0.005% (@ 100 mW/1.27V 16
Ohm)
SNR:
Balanced >121dBA (@ 15.2V )
Single-Ended >120dBA (@ 7.6V )
Max Output:
Balanced 7.4V RMS
RCA 3.8V RMS
3.5mm 1.92V RMS
Gain: 0dB, 6dB, 12dB and 18dB
Frequency Response: 10Hz - 200kHz (-3dB)
Power consumption:
No Signal ~5W
Max Signal ~12W
Dimensions: 158 x 117 x 35 mm / 6.2" x 4.6" x 1.4"
Net weight: 550 g / 1.21 lbs
Line Section
Outputs:
Balanced 6.7V max. (variable)
UnBAL 3.5V max. (variable)
Output Impedance:
Balanced ≤200Ω
UnBAL ≤100Ω
SNR:
Balanced <110dB(A) @ 0dBFS
UnBAL <110dB(A) @ 0dBFS
THD+N:
Balanced <0.007% @ 0dBFS
UnBAL <0.015% @ 0dBFS
Headphone Section
Outputs:
Balanced 6.7V max. @ 600 Ω
UnBAL 3.5V max. @ 600 Ω
Output Power:
Balanced >1000mW @ 32Ω; >74mW @ 600Ω
UnBAL >320mW @ 32Ω; >40mW @ 300Ω
Output Impedance:
Balanced <1Ω
UnBAL <1Ω
SNR:
Balanced <116dB(A) @ 0dBFS
UnBAL <115dB(A) @ 0dBFS
THD+N <0.005% (1V @ 16Ω)
