Inputs: 2 x XLR, 2 x RCA, parallel
Recommended input voltage: 0 dBV, 1 Vrms
Min. input impedance, 5 Hz – 20 kHz: 100 kΩ, 9 pF effective input capacitance
Outputs: 2 x 6.35 mm jack, 1 x XLR4
Max. output voltage, 5 Hz – 20 kHz: 19 dBV, 9 Vrms @ 0,01% THD
Recommended max. load, 5 Hz – 20 kHz: 10 Ω – 600 Ω, max. 150 nF
THD + N, 5 Hz – 20 kHz: <0.002 %, @ 10 Ω, 1.0 W, measuring bandwidth 90 kHz
THD + N, 1 kHz: 0.0005 %, @ 10 Ω, 1.0 W, measuring bandwidth 22 kHz
THD + N, 1 kHz: 0.0004 %, @ 22 Ω, 0.4 W, measuring bandwidth 22 kHz
Amplification, no load: 9.96 dB
Volume attenuation: -90 dB
SINAD, 20 kHz bandwidth, 1 kHz: min. 86 dB @ 50 mVrms / 107 dB @ 3Vrms power bandwidth (-3 dB) 5 Hz – 2 MHz
Rise time, constant: 0.25 µs
Max. slew rate: 200 V/µs
Min. damping factor, 5Hz – 20 kHz, XLR4: 200 @ 8 Ω
Self-noise, volume at min., no input: EIN = 136 dB(A) / 1,5 µVrms(A)
Protection circuits: mains overvoltage, output over current, output DC-Offset detection, overt emperature, mains failure
Power rating: 100-120 V~ / 220-240 V~, 50 / 60 Hz, 10W idle, max. 25W
Dimensions: 265 mm x 220 mm x 65 mm
Weight: 2.8 kg (6 lb, 2.7 oz)
