Turntable
Turntable Type: Direct Drive
Turntable Speeds: 33 1/3, 45 RPM
Torque: 1.6kg/cm
Wow and Flutter: <0.1%
Platter Material: POM (Polyoxymethylene)
Platter Diameter: 305mm
Tonearm
Type: Static balanced tonearm with removable headshell
Effective Length: 221.5mm
Overhang: 19mm
Effective Mass: 19.6g
Internal Phono Stage
Gain @ 1kHz: 42dB
Nominal Output (supplied cartridge): 250m VRMS
Equivalent Input Noise (A weighted): 0.1u VRMS
RIAA Curve Accuracy: +/- 0.3dB 30Hz-20kHz
Signal/Noise Ratio (Ref 1V OUT, 20-20k BW): >90dB
THD+N 1kHz: 0.0025%
Input Impedance: 47kΩ
Input Capacitance: 330pF
Outputs
Audio Output: RCA phono/line level (switchable)
Bluetooth: SBC/aptX/aptX HD
General
Power Supply: AC 100-240V, 50/60Hz
Power Consumption: 5.5W approx, 20W max, <0.25W (Standby)
Dimensions (W x H x D): 435 x 139 x 368 mm
Weight: 10.9kg
Cartridge
Type: High output moving coil
Frequency Response: +/- 1dB 30Hz-20kHz
Stylus: Elliptical
Cantilever: Aluminium
Output Level: 2mV @ 1kHz
Recommended Tracking Force: 2g
Recommended Load: 47kΩ
