DIMENSIONS: 95 (l) x67 (w) x19 (h) mm
FREQUENCY RESPONSE: < 2Hz – > 200kHz (-3dB)
GAIN: -95dB to +18dB adjustable in 114 1dB steps (using volume control)
INPUT:
Wireless: ESS Sabre 44.1/48k 16-Bit (AAC, aptX, aptX LL and SBC)(@ 3.8V)
Wired: 3.5mm (TRS or TRRS S-Balanced*) and 2.5mm (TRRS)
*ONLY found in iFi components such as nDSD BL. Do NOT feed using normal TRRS Balanced output sources. No USB audio input
MAXIMUM INPUT LEVEL:
S-Balanced: 3V RMS
Balanced: 6V RMS
MAXIMUM OUTPUT POWER:
S-Balanced: > 3.8V / 45 mW (@ 300 Ohm)> 3.5V / 380 mW (@ 32 Ohm)> 3.1V / 600 mW (@ 16 Ohm
Balanced: > 7.6V / 90 mW (@ 600 Ohm)> 7.2V / 800 mW (@ 64 Ohm)> 5.7V / 1,000 mW (@ 32 Ohm)
NET WEIGHT: 127g (0.28 Ibs)
OUTPUT IMPEDANCE:
S-Balanced: <1 Ohm
Balanced: <2 Ohm
PLAYBACK TIME: 18 hours (analogue) or 12 hours (Bluetooth) (charging via USB port)
RECOMMENDED HP IMPEDANCE: 16~600 Ohm
SNR:
S-Balanced: > 121dBA (@ 3.8V)
Balanced: >120dBA (@ 7.6V)
THD+N:
S-Balanced: < 0.005% (@ 100 mW/1.26V 16 Ohm)
Balanced: < 0.006% (@ 360 mW/2.4V 16 Ohm)
